2000-MW Series Medical Adhesives

2101-MW-UR

LED-Curable Medical Wearable Adhesive For Skin Sensitivity Concerns


The 2101-MW-UR is blazing the trail for the next generation in advanced medical-grade adhesives for wearables. As part of the 2000-MW product line, these adhesives are specifically designed to address skin sensitivity concerns through the removal of IBOA (isobornyl acrylate). 2101-MW-UR adhesive passes ISO 10993-10 skin irritation and sensitization, ISO 10993-23 intracutaneous irritation, and ISO 10993-5 cytotoxicity testing, making it an ideal option for smart medical wearable devices.

2101-MW-UR is a light-cure adhesive that bonds using LED or ultra-violet light with a medium viscosity. The material also uses Ultra-Red® fluorescing for simple in-line inspection of UV curing materials. The medical adhesive forms a highly reliable bond to many plastics such as ABS, PC, PCTG, PETG, PVC, and TPU. This makes it an ideal substance to use for the assembly of medical smart devices, patient monitoring devices, large-volume injectors, or diabetes care devices.

2101-MW-UR medical wearable device adhesive is in full compliance with RoHS directives 2015/863/EU.

Features

  • ISO 10993-10 (passes testing for skin irritation & sensitization)
  • ISO 10993-5 (passes testing for cytotoxicity)
  • ISO 10993-23 (passes testing for intracutaenous irritation)
  • TPO Free (designed without Diphenyl Trimethylbenzoyl Phosphine Oxide)
  • IBOA Free (designed without isobornyl acrylate)
  • Ultra-Red® Fluorescing for inspection

Typical Properties

Looking for additional technical specifications. Download a Product Datasheet in our Resource Library or talk with our technical experts.

Get in touch
Property Values
Viscosity, cP (20rpm) (nominal) 5,500
Cured durometer hardness D77
Tensile at break 24.8 [3,600]
Cured elongation at break 80%
Modulus of Elasticity, MPa [psi]: 1020.4 [148,000]
Boiling Water Absorption, % (2hr.) 4.5
Water Absorption, % (25°C, 24hr.) 2:1
Fluoresces Yes
Recommended substrates: ABS, PC, PCTG, PETG, PVC, TPU

Looking for additional technical specifications. Download a Product Datasheet in our Resource Library or talk with our technical experts.

Get in touch

Request a Quote

Ready to take the next step? Dymax team member will get back to you shortly.

Biocompatible Adhesives for Medical Wearable Device Assembly

The 2000-MW series of light-curable adhesives are a first-of-kind dedicated series of products for assembling medical wearables. Free from TPO, a material of concern, and made without IBOA, a known skin irritant, these adhesives address device manufacturers’ concerns about skin proximity and sensitivity.

Dymax Adhesives for Wearable Medical Device Assembly

With wearable medical devices' constant proximity to skin, biocompatibility is a must. Our MW-series adhesives meet strict industry standards, passing ISO 10993 for cytotoxicity, sensitization, and irritation. They are also formulated without IBOA to be friendlier to skin, and without TPO or solvents for a safer product, workplace and environment.

BCE Application Engineers support all your technical requirements.

Our technical experts are ready to answer any product or application questions you may have
